 PVC SYSTEMS

META 82 MD

  • V Perfect welding
  • Profile system 7 chambers - frame
  • Base width 82mm
  • Rigid central gasket system
  • Galvanized steel reinforcement 1.5 - 2.00 mm
  • Possibility of triple glazing - 44mm, 52mm,
  • Squared glazing bead
  • Colours: glossy white extruded PVC, wood effect film, standard or non-standard colors to order, two-tone to order, ultra matt.
  • Gasket colour: Light grey / Caramel / Black
  • Hardware: Maco
  • Handle: HOPPE
  • Thermal transmittance coefficient (profile): 1.0 W/m²K
  • Possibility of system with 35 or 60mm Z frame

META 76 MD

  • V Perfect welding
  • 6 chamber profile system
  • Base width 76mm
  • Rigid central gasket system
  • Galvanized steel reinforcement 1.5 - 2.00 mm
  • Possibility of double or triple glass - 28mm, 32mm, 44mm
  • Squared glazing bead
  • Colours: glossy white extruded PVC, wood effect film, standard or non-standard colors to order, two-tone to order, ultra matt.
  • Gasket colour: Light grey / Caramel / Black
  • Hardware: Maco
  • Handle: HOPPE
  • Thermal transmittance coefficient (profile): 1.1 W/m²K
  • Possibility of system with 35 or 60mm Z frame

META 74MD

V Perfect welding
6 chamber profile system
Base width 74mm
Rigid central gasket system
Galvanized steel reinforcement 1.5 - 2.00 mm
Possibility of double or triple glass - 28mm, 32mm, 44mm
Squared glazing bead cut 90°
Colours: glossy white extruded PVC, wood effect film, standard or non-standard colors to order, two-tone to order.
Gasket colour: Light grey / Caramel / Black
Hardware: Maco
Handle: HOPPE
Thermal transmittance coefficient (profile): 1.1 W/m²K
Possibility of system with 35 or 60mm Z frame

COLORS

META MOTION 82

Designed to reduce the presence of the frame and give greater value to glass, which is increasingly requested as an element within modern homes. The visual impact of the frames is reduced by 20%, leaving ample space for the glass surface. This type of system represents an innovative and high-performance solution for sliding windows, guaranteeing smooth and silent operation, excellent air and water tightness and an improvement in living comfort, leaving more space inside your home. The floor threshold also helps to leave more space for the glass, lightening the structure; it allows the installation of both standard and barrier-free solutions.

ULTRA MATT

Newly developed surface that gives PVC windows an unprecedented aesthetic dimension. Extremely resistant to atmospheric agents. Unalterable color. Acrylic glass is an extremely stable and light-resistant material. Easy maintenance. The surface is water-repellent and easy to clean thanks to the anti-fingerprint effect. They do not absorb dirt and keep their beauty intact. Scratchproof. The surface is scratch-resistant and robust. The acrylic layer is approximately 0.5 mm thicker than any paint layer

META 70

5 chamber profile system
Base width 70mm
Galvanized steel reinforcement 1.5 - 2.00 mm
Possibility of double or triple glass - 24mm, 30mm, 36mm
Rounded glazing bead
Colours: glossy white extruded PVC, wood effect film, standard or non-standard colors to order, two-tone to order.
Gasket colour: Light grey / Black
Hardware: Maco
Handle: HOPPE
Thermal transmittance coefficient (profile): 1.3 W/m²K
Possibility of system with 35 or 60mm Z frame
